High Efficiency Permanent Magnet Generator with Low RPM and IP54 Protection for Energy Conversion

High Efficiency Permanent Magnet Generator with Low RPM and IP54 Protection for Energy Conversion

Marca:

Greef

Certificação:

CE

Model Number:

GDF

Contacte-nos
Solicite um orçamento
High Efficiency Permanent Magnet Generator with Low RPM and IP54 Protection for Energy Conversion
High Efficiency Permanent Magnet Generator with Low RPM and IP54 Protection for Energy Conversion
Detalhes do produto
Effienciency:
>95%
Tipo de gerador:
3 Fase AC Ímã permanente
Nível de IP:
IP67
Nome do produto:
Gerador de imã permanente
Pólo:
2-48
Tipo atual:
AC
Material de enrolamento:
S
Velocidade nominal de rotação:
20 rpm-3000 rpm
Termos de pagamento e envio
Minimum Order Quantity
1 Set
Preço
Negociável
Packaging Details
Foam+plywooden Case
Delivery Time
25 Working Days
Payment Terms
T/T
PRODUTOS RELACIONADOS
Bom preço. High Efficiency Permanent Magnet Generator with Low RPM and IP54 Protection for Stable Power Output on-line vídeo

High Efficiency Permanent Magnet Generator with Low RPM and IP54 Protection for Stable Power Output

Obtenha o melhor preço
Bom preço. IP54 Protected Permanent Magnet Generator with 20rpm-3000rpm Rated Speed for Horizontal or Vertical Installation on-line vídeo

IP54 Protected Permanent Magnet Generator with 20rpm-3000rpm Rated Speed for Horizontal or Vertical Installation

Obtenha o melhor preço
Bom preço. High Efficiency Permanent Magnet Generator with 2 to 48 Poles and 20rpm-3000rpm Speed Range on-line vídeo

High Efficiency Permanent Magnet Generator with 2 to 48 Poles and 20rpm-3000rpm Speed Range

Obtenha o melhor preço
Bom preço. High Efficiency Permanent Magnet Generator with NdFeB Magnet Type and IP54 Protection Grade for Reliable Power Generation on-line vídeo

High Efficiency Permanent Magnet Generator with NdFeB Magnet Type and IP54 Protection Grade for Reliable Power Generation

Obtenha o melhor preço
Contacte-nos
Contacte agora
Descrição do produto
2 to 48 Pole Permanent Magnet Generator Offering Efficiency Above 95%
High Efficiency Permanent Magnet Generator with Low RPM and IP54 Protection for Energy Conversion 0
Product Overview
The fundamental concept behind a permanent magnet generator lies in the rotor incorporating permanent magnet materials to produce a steady magnetic field. This magnetic field remains constant due to the inherent properties of the permanent magnets embedded within the rotor.
When an external prime mover, such as a wind turbine, water turbine, or an engine, drives the rotor to spin, the magnetic field created by the rotor rotates as well. As this rotating magnetic field passes through the stator windings, it interacts with the conductors wound around the stator.
Based on the law of electromagnetic induction, the movement of the magnetic field relative to the stator windings induces an electromotive force (EMF) within those windings. By connecting an external load or circuit to the stator, the generator can deliver electrical power generated from mechanical energy.
Key Features
  • Direct drive system with simple and robust design, eliminating the need for a gearbox
  • Brushless mechanism ensuring minimal maintenance and increased reliability
  • High efficiency exceeding 95% with power factor close to 1
  • Inserted Nd-Fe-B permanent magnets supporting both clockwise and anticlockwise rotations
  • Capable of generating high voltage and power even at low speeds
  • Long service life exceeding 20 years with continuous 24/7 operation capability
  • Customizable voltage, speed, power, frequency, and other specifications
  • 3-year free guarantee period with lifelong maintenance and service support
Technical Specifications
Parameter Specification
Rated Power 0.5 kW to 5000 kW
Rated Speed 20 to 3000 rpm
Frequency 50 to 60 Hz
Generator Type Synchronous 3-phase AC
Number of Poles 2 to 48
Magnet Type NdFeB
Winding Method Y-type
Magnet Temperature Up to 120℃
Winding Temperature Up to 180℃
Efficiency > 95%
Insulation Grade H
Insulating Resistance ≥ 100 MΩ at 500 V DC
Housing Material Cast Iron
Windings 100% Copper
Iron Core Cold-rolled Silicon Steel Sheet
Shaft Material Steel
Bearings SKF Brand
Cooling System Fan Cooling
Protection Grade IP54
Installation Horizontal and Vertical
Weight Approximately 1200 kg
High Efficiency Permanent Magnet Generator with Low RPM and IP54 Protection for Energy Conversion 1
Applications
  • Wind Power Generation: Core component in modern direct-drive and semi-direct-drive wind turbines
  • Marine and Offshore: Ship shaft generators and main/auxiliary power systems
  • Backup Power Systems: Diesel and gas generator sets for emergency power
  • High-Speed Applications: Microturbines and flywheel energy storage systems
  • Industrial Sectors: Specialized contexts requiring high power density and exceptional reliability
Customization Options
Model: GDF | Origin: China | Cooling: Fan | Efficiency: >95%
Protection: IP54 | Certification: CE | Current Type: AC
Operation: Low speed with low start torque
We provide flexible customization with minimum order quantity of 1 set. Pricing is negotiable based on project requirements. Delivery time is typically 25 working days with payment terms based on T/T.
Packaging and Shipping
Each Permanent Magnet Generator is carefully packaged with anti-static foam and bubble wrap for protection during transit. The generator is placed in sturdy corrugated cardboard boxes with additional padding materials. Larger models are packed in wooden crates for extra durability.
All packaging materials are environmentally friendly and recyclable. Shipping options include air, sea, and land transportation. Packages are clearly labeled with handling instructions and tracking information is provided.
High Efficiency Permanent Magnet Generator with Low RPM and IP54 Protection for Energy Conversion 2
