Para casa > produtos > gerador de ímã permanente >
AC Current Type Permanent Magnet Generator with Rated Voltage 12-1140V and Robust Steel Shaft Material

AC Current Type Permanent Magnet Generator with Rated Voltage 12-1140V and Robust Steel Shaft Material

Rated Voltage 12-1140V Permanent Magnet Generator

AC Current Type PMG

Robust Steel Shaft Material Permanent Magnet Alternator

Marca:

Greef

Certificação:

CE

Model Number:

GDF

Contacte-nos
Solicite um orçamento
AC Current Type Permanent Magnet Generator with Rated Voltage 12-1140V and Robust Steel Shaft Material
AC Current Type Permanent Magnet Generator with Rated Voltage 12-1140V and Robust Steel Shaft Material
Detalhes do produto
Voltag avaliado:
12-1140V
Marca do rolamento:
SKF
Tipo de ímã:
NdFeB
Potência nominal:
0,5-5000KW
Método de resfriamento:
Resfriamento do ventilador
Proteção G:
IP54
Tipo de gerador:
gerador síncrono da C.A. 3phase
Material do invólucro do gerador:
ferro fundido
Termos de pagamento e envio
Minimum Order Quantity
1 Set
Preço
negotiable
Packaging Details
Foam+plywooden Case
Delivery Time
25 Working Days
Payment Terms
T/T
PRODUTOS RELACIONADOS
Bom preço. 12-1140V Rated Voltage 0.5-5000KW Rated Power IP54 Protection Permanent Magnet Generator PMG for High Efficiency Applications on-line vídeo

12-1140V Rated Voltage 0.5-5000KW Rated Power IP54 Protection Permanent Magnet Generator PMG for High Efficiency Applications

Obtenha o melhor preço
Bom preço. 0.5-5000KW Rated Power 12-1140V Permanent Magnet Generator with Long-lasting Copper Stator and PMG Design on-line vídeo

0.5-5000KW Rated Power 12-1140V Permanent Magnet Generator with Long-lasting Copper Stator and PMG Design

Obtenha o melhor preço
Bom preço. High Efficiency Permanent Magnet Generator with Max.120℃ Magnet Temperature and Max.180℃ Winding Temperature for Heavy Duty Applications on-line vídeo

High Efficiency Permanent Magnet Generator with Max.120℃ Magnet Temperature and Max.180℃ Winding Temperature for Heavy Duty Applications

Obtenha o melhor preço
Bom preço. High Efficiency Permanent Magnet Generator with Cast Iron Shell Copper Stator and NdFeB Magnet on-line vídeo

High Efficiency Permanent Magnet Generator with Cast Iron Shell Copper Stator and NdFeB Magnet

Obtenha o melhor preço
Contacte-nos
Contacte agora
Descrição do produto
AC Current Type Permanent Magnet Generator with Rated Power 0.5-5000KW and Robust Steel Shaft Material
AC Current Type Permanent Magnet Generator with Rated Voltage 12-1140V and Robust Steel Shaft Material 0
Permanent Magnet Generator (PMG): A Leap in Power Generation Efficiency
A Permanent Magnet Generator (PMG) is an advanced type of electric generator that utilizes high-strength permanent magnets on its rotor to create a powerful magnetic field, instead of relying on traditional electrically-excited windings.
This innovative design eliminates the need for slip rings and brushes, leading to significant advantages:
  • Higher Efficiency: Reduces energy losses, resulting in superior efficiency, especially under partial loads.
  • Exceptional Reliability: Brushless structure ensures minimal maintenance and a longer operational lifespan.
  • Compact & Lightweight: Offers a higher power density, making it ideal for space-constrained applications.
  • Excellent Performance: Provides superior voltage regulation and faster response.
PMGs are the ideal power solution for wind turbines, marine applications, backup power systems, and any scenario demanding reliable and efficient energy conversion.
Applications
Permanent Magnet Generators (PMGs), noted for their high efficiency, reliability, and compact design, have emerged as the favored power solution in various contemporary industrial sectors. Major application areas encompass:
Wind Power Generation
The primary element in present-day direct-drive and semi-direct-drive wind turbines, offering exceptional efficiency, particularly in variable-speed operation.
New Energy Vehicles
Extensively utilized in electric and hybrid vehicles as the principal traction motor or auxiliary generator.
Marine and Offshore
Admirable for ship shaft generators and main/auxiliary power systems owing to their high reliability and low maintenance.
Backup Power Systems
Deployed in diesel and gas generator sets to furnish responsive, stable, and reliable emergency and standby power.
High-Speed Applications
Appropriate for high-speed drives like microturbines and flywheel energy storage systems.
Industrial & Military Equipment
Utilized in specialized and military power systems where high power density and utmost reliability are crucial.
Product Parameters
Parameter Value Unit
Rated power 0.5-5000 kW
Rated rotate speed 20-3000 rpm
Rated voltage 48-1140 Vac
Frequency 60/50 Hz
Number of Poles 24
Generator type 3phase AC Synchronous generator
Magnet type NdFeB
Winding Method Y
Magnet temperature level Max.120℃
Winding temperature level Max.180℃
Effienciency >95%
Insulate Grade H
Insulating resistance 100Mohm Min(500Vdc)
Classification of degrees IP54
Generatror shell material Cast Iron
Winding material 100% Copper
Shaft material Steel
Iron Core Cold rolled silicon steel sheet
Bearing brand SKF
Cooling Method Fan Cooling
Weight (N.W /G.W ) 132kg /152kg
Packing Size 870*470*570mm
Installation Horizontal
Rated Power Specifications
Rated Power Rated Speed Rated Voltage Frequency
0.5KW 20rpm~400rpm 12V~220Vac 10Hz~60Hz
1KW 20rpm~600rpm 12V~220Vac 10Hz~60Hz
2KW 20rpm~1000rpm 12V~400Vac 10Hz~60Hz
3KW 20rpm~1500rpm 48V~690Vac 10Hz~60Hz
5KW 20rpm~1500rpm 48V~690Vac 10Hz~60Hz
10KW 20rpm~1500rpm 120V~690Vac 10Hz~60Hz
15KW 20rpm~3000rpm 120V~690Vac 10Hz~60Hz
20KW 20rpm~3000rpm 120V~690Vac 10Hz~60Hz
25KW 20rpm~3000rpm 120V~1140Vac 10Hz~60Hz
30KW 20rpm~3000rpm 120V~1140Vac 10Hz~60Hz
50KW 20rpm~3000rpm 220V~1140Vac 10Hz~60Hz
80KW 20rpm~3000rpm 220V~1140Vac 10Hz~60Hz
100KW 20rpm~3000rpm 220V~1140Vac 10Hz~60Hz
150KW 20rpm~3000rpm 380V~1140Vac 10Hz~60Hz
200KW 20rpm~3000rpm 380V~1140Vac 10Hz~60Hz
250KW 20rpm~3000rpm 380V~1140Vac 10Hz~60Hz
300KW 20rpm~3000rpm 380V~1140Vac 10Hz~60Hz
500KW 20rpm~3000rpm 380V~1140Vac 10Hz~60Hz
700KW 20rpm~3000rpm 690V~1140Vac 10Hz~60Hz
800KW 20rpm~3000rpm 690V~1140Vac 10Hz~60Hz
1MW 200rpm~3000rpm 690V~1140Vac 10Hz~60Hz
2MW 200rpm~3000rpm 690V~1140Vac 10Hz~60Hz
3MW 200rpm~3000rpm 690V~1140Vac 10Hz~60Hz
20KW 20rpm~3000rpm 120V~690Vac 10Hz~60Hz
4MW 600rpm~3000rpm 690V~1140Vac 10Hz~60Hz
5MW 600rpm~3000rpm 690V~1140Vac 10Hz~60Hz
Customization
Product Customization Services for the Permanent Magnet Generator
Brand Name:
Greef
Model Number:
GDF
Place Of Origin:
China
Certification:
CE
Minimum Order Quantity:
1 Set
Price:
Negotiable
Packaging Details:
Foam+plywooden Case
Delivery Time:
25 Working Days
Payment Terms:
T/T
Current Type:
AC
Generator type:
3phase AC Synchronous Generator
Protection G:
IP54
Shaft material:
Steel
Rated Power:
0.5-5000KW
Keywords:
FREE ENERGY, three phase, magnetic power generator
Packing and Shipping
Our Permanent Magnet Generator product is carefully packaged to ensure safe delivery to our customers. Each generator is securely wrapped in protective materials to prevent any damages during transportation.
Shipping Information
We offer worldwide shipping for our Permanent Magnet Generator. Shipping costs may vary depending on the destination and shipping method chosen. Customers can track their orders and receive updates on the delivery status.
