O produto adota um design do tipo pedestal, formato bonito e movimento conveniente; incluindo o protocolo de inversor do mercado principal, comunica-se diretamente; adota uma estratégia abrangente e multinível de proteção da bateria e medidas de isolamento de falhas para garantir a operação segura do sistema. Amplamente utilizado em pequenos comércios e armazenamento de energia familiar.
Parâmetros do Produto
Modelo
GBP48-280H
GBP48-314H
GBP51.2-280H
GBP51.2-314H
Tensão nominal (V)
48
51.2
Especificação da célula (Ah)
280
314
280
314
Capacidade nominal (Ah)
280
314
280
314
Faixa de tensão de trabalho
42~54.75
44.8~58.4
Tensão de carregamento recomendada (V)
51.75
55.2
Corrente de carregamento padrão (A)
100
Corrente máxima de carregamento contínuo (A)
150
Corrente de descarga padrão (A)
100
Corrente máxima de descarga (A)
150
Temperatura adequada (℃)
-30~60 (Recomendado 10~35)
Faixa de umidade permitida (%UR)
85
Temperatura de armazenamento (℃)
-20~65 (Recomendado 10~35)
Nível de proteção
IP20
Método de resfriamento
Resfriamento a ar natural
Tamanho máximo (P*L*A)mm
246*480*990
Peso líquido (kg)
138.5
142.5
141
145
Detalhes do Produto
Solução do Sistema
Este diagrama do sistema é apenas para referência, se você tiver outros requisitos,entre em contato conosco!
