Módulo Bluetooth. Peças do aquecedor (200W), caixa de distribuição (para ligação paralela)
Modelo
HV RESS- 72
Módulo de bateria
51,2V 72Ah (3,68KWH)
Número de módulos de bateria
4
5
6
7
8
Energia total [kWh]
14,7
18,4
22,0
25,7
29,4
Tensão nominal[Vdc]
204,8
256
307,2
358,4
409,6
Faixa de tensão [Vdc]
160~240
200~300
240~360
280~420
320~480
Corrente máx. de carregamento [A]
50
Corrente máx. de descarga [A]
50
Corrente de descarga de pulso
100A/10s
Potência máx. do inversor[W]
10000
12800
15360
17920
20480
Faixa de temperatura de operação
Carga:0~+55°C;Descarga:-20~+55C
Humidade de operação
Modelo
HV RESS- 100
Módulo de bateria
51,2V 100Ah (5,12KWH)
Número de módulos de bateria
4
5
6
7
8
Energia total [kWh]
20,5
25,6
30,7
35,8
40,9
Tensão nominal[Vdc]
204,8
256
307,2
358,4
409,6
Faixa de tensão [Vdc]
160~240
200~300
240~360
280~420
320~480
Corrente máx. de carregamento [A]
50
Corrente máx. de descarga [A]
50
Corrente de descarga de pulso
100A/10s
Potência máx. do inversor[W]
10000
12800
15360
17920
20480
Faixa de temperatura de operação
Carga:0~+55°C;Descarga:-20~+55C
Humidade de operação
0~95% RH (Sem condensação)
Interface de comunicação
CAN*1,DI*1,DO*2
Vantagens das baterias de lítio
1. Alta densidade de energia: A alta densidade de energia das baterias de lítio pode fornecer mais energia, permitindo que as novas turbinas de energia operem com mais eficiência. 2. Longa vida útil: A longa vida útil das baterias de lítio reduz a frequência de substituição da bateria, reduzindo assim os custos de manutenção. 3. Boa segurança: Em comparação com outros tipos de baterias, as baterias de lítio têm melhor desempenho de segurança, o que pode efetivamente evitar incêndios e outros acidentes. 4. Tempo de resposta rápido: As baterias de lítio têm um tempo de resposta rápido e podem fornecer rapidamente a energia elétrica necessária, permitindo que as novas turbinas de energia liguem e desliguem mais rapidamente. 5. Ecológico: As baterias de lítio são um tipo de bateria ecologicamente correta que não polui o meio ambiente.
